back to SKF PRODUCTS » Rod Seals
| UBR SEALS | |||
 |
HEAVY DUTY MOBILE HYDRAULIC |
HIGH DUTY CYCLE Pressure: 400 bar Temperature: -40°C - +120°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
U-1023 HP LUBRITHANE® U-1028 EXHP LUBRITHANE U-1027 EXHP LUBRITHANE |
| UNSYMETRICAL U-CUP | |||
 |
MOBILE HYDRAULIC AGRICULTURAL GENERAL INDUSTRIAL |
MEDUIM DUTY CYCLE Pressure: 400 bar Temperature: -40°C - +120°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
U-1023 HP LUBRITHANE U-1028 EXHP LUBRITHANE U-1027 EXHP LUBRITHANE |
| TYPE B POLYSEAL | |||
 |
MOBILE HYDRAULIC AGRICULTURAL GENERAL INDUSTRIAL |
HIGH DUTY CYCLE Pressure: 400 bar Temperature: -40°C - +120°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
U-1003 LUBRITHANE (100°C) U-1023 HP LUBRITHANE U-1028 EXHP LUBRITHANE |
| DEEP Z-SEAL | |||
 |
HEAVY DUTY MOBILE HYDRAULIC TELESCOPIC CYLINDER |
HIGH DUTY CYCLE Pressure: 400 bar Temperature: -54°C - +105°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
U-1003 LUBRITHANE (100°C) A-8504 LOW-TEMP. NITRILE LIP U-1003 LUBRITHANE BASE |
| DEEP Z-SEAL WITH DELTA ANTI - EXTRUSION RING | |||
 |
HEAVY DUTY MOBILE HYDRAULIC HIGH PRESSURE |
HIGH DUTY CYCLE Pressure: 500 bar Temperature: -54°C - +105°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
A-8504 LOW-TEMP NITRILE LIP U-1003 LUBRITHANE BASE (100°C) P-2506 NYLON ANTI-EXTRUSION |
