back to SKF PRODUCTS » Piston Seal
| LOCKING CAPPED T-Seal | |||
 |
HEAVY DUTY MOBILE HYDRAULIC |
HIGH DUTY CYCLE Pressure: 500 bar Temperature: -40°C - +125°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
702 15% GLASS, 5% MOLY PTFE 740 40% BRONZE PTFE A-8501 NITRILE P-2506 NYLON |
| CAPPED T-Seal® | |||
 |
HEAVY DUTY MOBILE HYDRAULIC |
HIGH DUTY CYCLE Pressure: 500 bar Temperature: -40°C - +125°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
702 15% GLASS, 5% MOLY PTFE 740 40% BRONZE PTFE A-8501 NITRILE P-2506 NYLON |
| GROOVED PISTON SEAL | |||
 |
ACCUMULATORS HEAVY DUTY MOBILE HYDRAULIC GEN. MACHINE |
MEDIUM DUTY CYCLE Pressure: 350 bar Temperature: -40°C - +200°C Velocity: 0,5 m/s max Surface Finish: Ra 0,1-0,3 μm |
741 40% BRONZE PTFE Customer-Supplied O-Ring and Quad Ring Required. |
| PTFE PISTON SEAL | |||
 |
AGRICULTRUAL HEAVY DUTY MOBILE HYDRAULIC GEN. MACHINE |
HIGH DUTY CYCLE Pressure: 350 bar Temperature: -40°C - +200°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
702 15% GLASS, 5% MOLY PTFE 711 25% CARBON GRAPHITE PTFE 714 55% BRONZE, 5% MOLY PTFE 741 40% BRONZE PTFE Customer Supplied O-Ring Required |
| PTFE PISTON S-RING | |||
 |
MEDIUM OPERATION MOBILE HYDRAULIC |
HIGH DUTY CYCLE Pressure: 350 bar Temperature: -40°C - +200°C Velocity: 1,0 m/s max Surface Finish: Ra 0,1-0,4 μm |
714 55% BRONZE, 5% MOLY PTFE A-8501 NITRILE Customer Supplied NBR loader required. |
| CROWN SEAL | |||
 |
AGRICULTURAL HEAVY DUTY MOBILE HYDRAULIC |
MEDIUM DUTY CYCLE Pressure: 350 bar Temperature: -40°C - +120°C Velocity: 0,1 m/s max Surface Finish: Ra 0,1-0,4 μm |
U-1003 LUBRITHANE (100°C) U-1023 HP LUBRITHANE |
| UNSYMETRICAL U-Cup | |||
 |
AGRICULTURAL GENERAL INDUSTRIAL |
MEDIUM DUTY CYCLE Pressure: 350 bar Temperature: -65°C - +120°C Velocity: 0,5 m/s max Surface Finish: Ra 0,1-0,4 μm |
U-1003 LUBRITHANE (100°C) U-1023 HP LUBRITHANE |
